Juice Making Washing Filling Capping Machines/production Line/packing Machine
1, Introduce
Beverage filling machine is a piece of equipment specially used to fill beverages into glass bottles, tinplate cans and PET bottles. It is widely used in the food and beverage industry for its efficiency, accuracy and reliability.
2, Main Technical Parameter
| Model |
Filler volume |
Air consumption |
Filling accuracy |
Total power |
Machine size(mm) |
| LW-FPP-4A |
10-60g |
120L/Min |
liqud≤±0.5%Paste≤±1% |
3P 380V,50/60Hz 1.369KW |
L2200*W1020*H2250 |
| LW-FPP-6A |
30-100g50-250g |
140L/Min |
liqud≤±0.5%Paste≤±1% |
3P 380V,50/60Hz1.69KW |
L2500×W1020×H2250 |
| LW-FPP-8A |
100-500g |
160L/Min |
liquid≤±0.5%Paste≤±1% |
3P 380V,50/60Hz 2.07KW |
L2500×W1020× H2250 |
| LW-FPP-10A |
200-1000g500-2500ml |
180L/Min |
liquid≤±0.5%Paste≤±1% |
3P 380V,50/60Hz 2.82kw |
L3000×W1020×H2250 |
| LW-FPP-12A |
1000-5000ml |
300L/Min |
liquid≤±0.5%Paste≤±1% |
3 P 380V,50/60Hz 2.82kw |
L3000×W1020×H2250 |
3, Features
1, Preventing Leaking System
2, No Bottle or Lack of Bottle, No Filling System
3, Photoelectric Sensor, Mechatronics Filling Adjustment System
4, Photoelectric Sensor, Material Level Control Feeding System
5, Stainless Steel Frame, Plexiglass as Security Cover
6, Control System: PLC/Electronic-Pneumatic Controlled
7, Operation Panel: "Intelligent" Colorful Touch Screen
8,Filling Accuracy:+-0.5%—1%
9, Capacity Adjustment: All cylinders adjusted automatically combine single cylinder adjusted individually.
10, Container transport: Stainless steel frame and engineering plastic plate chain variable speed conveyor, with photoelectric sensor.
4, Application
